How to backup files from one server to another server using rssnapshot?
In this tutorial, we will setup backup in on server, which will pull data from main server as backup files. This way, if the main server goes offline, all our important files will be there in backup server. For this we will use ‘rsnapshot’. rsnapshot is based on rsync and can be used to backup in remote server or different server.
Since we are backing up in stand alone or different server, all the setup we are doing is in backup server. Before we start with rsnapshot make sure your backup server has ssh access to your main server. To enable ssh in backup server please read this article to create ssh login.
We also need third party repository called EPEL, so that we can install rsnapshot by ‘yum’ command.
1) Install rsnapshot via Yum:
yum install rsnapshot
if you get message like package not found, them please update your repository with EPEL. To update your repo follow following:
RHEL/Centos 7 64-Bit:
wget http://dl.fedoraproject.org/pub/epel/beta/7/x86_64/epel-release-7-0.2.noarch.rpm rpm -ivh epel-release-7-0.2.noarch.rpm
RHEL/Centos 6 64-Bit:
wget http://download.fedoraproject.org/pub/epel/6/x86_64/epel-release-6-8.noarch.rpm rpm -ivh epel-release-6-8.noarch.rpm
RHEL/Centos 6 32-Bit: wget http://download.fedoraproject.org/pub/epel/6/i386/epel-release-6-8.noarch.rpm rpm -ivh epel-release-6-8.noarch.rpm
2) Setup Config File:
vi /etc/rsnapshot.conf
In config file we are intend to do two things:
a) setup the interval for backup.
b) Setup location from where we need backup files and where to store it.
a) Set snapshot_root to path where you want to keep the backups:
snapshot_root /root/rsnapshot/
b) Set up the list of directories/files to back up.
look for “backup” text in config file, its in lower part of the file, here we can set multiple backup source and detination. format is
backup <source> <destination>
please note directory required trailing slash. so /etc is wrong while /etc/ is right format. And seperator is ‘TAB’ not just a space.
c) few examples of backup path setup.
i) If we want to back /folder/ from one location to another in same server we can do the following.
backup /folder/ localhost/
here every contain of /folder/ is backed up to /root/rssnapshot/localhost/
ii) Backing up files from remote server to current backup server.
Make sure you have ssh login access from backup server to remote server ( no password setup).
backup root@example.com:/home/mywebsite/ mywebsite/
here all the files of /home/mywebsite/ form remote server example.com will be backed up to /root/rsnapshot/mywebsite/ folders.
ii) Backing up mysql files to remote location.
Best way to backup mysql is create folder in your current server and run the cron script to dump mysql, and backing up that folder from remote rssnapshot script. But you can also find pre-created scripts in rssnapshot package.
a) copy script from rssnapshot utility.
cp /usr/share/doc/rsnapshot/examples/utils/backup_mysql.sh /usr/local/bin/
b) give proper permission to the file.
chown root.root /usr/local/bin/backup_mysql.sh
chmod o-w /usr/local/bin/backup_mysql.sh
c) edit script to suite your needs.
vi /usr/local/bin/backup_mysql.sh
d) Now finally edit rssnapshot.conf file to runbackup
backup_script /usr/local/bin/backup_mysql.sh localhost/mysqldump
d) Setup backup interval:
interval hourly 6 interval daily 7 interval weekly 4 interval monthly 3
This will take backup every six hours on a day. Define your own schedule as per your requirements.
3) Check config:
# rsnapshot configtest
4) Running Backup:
a) manually running
rsnapshot hourly
b) running as corn job
vi /etc/cron.d/rsnapshot
and paste following lines, you can change the timing as per your requirement.
0 */4 * * * root /usr/bin/rsnapshot hourly 30 3 * * * root /usr/bin/rsnapshot daily 0 3 * * 1 root /usr/bin/rsnapshot weekly 30 2 1 * * root /usr/bin/rsnapshot monthly
